This Carton Box Stretch Wrapping Machine is specifically designed for packing small and medium-sized objects in carton boxes.
Size of the product to be wrapped | |
Max carton size | 300-600mm (L) × 300-600mm (W) × 200-800mm(H) |
Max weight | 130 KG (Tailor -made) |
Film Carriage | |
Carriage | Power pre-stretch film carriage, stretch ratio up to 250% Film tension adjustable |
Machine Specification | |
Turntable speed: | 20 rpm |
Turntable height | 700mm |
Power supply voltage | 220 Volt 1 Ph - 50 Hz |
Power | 1.2 Kw Film carriage lift motor: 0.37kw Film feed motor:0.37kw Turntable motor: 0.4kw |
Packing efficiency | 20-40 loads/hour |
Machine weight | 300kg |
Stretch Film Roll detail | |
Max. external diameter (D): | 230 mm |
Internal diameter (d): | 76 mm |
Film roll height (h): | 500 mm |
Film thickness: | 17-35 µm |
Controls:
PLC controls wrap process.
Cycle pause capability.
0-20RPM adjustable
Pneumatic top plate.
Film carriage:
Film carriage is fixed for the box height, no need moving up-down;
Power pre-stretch 250%.
Film delivery variable speed by separate AC Drive Motor.
